Professional Grade Stitch Regulation.
The Perfect Stitch Regulator provides high-performance stitch regulation for long
or mid arm quilting machines. It is compatible with many popular brands, including:
A-1, ABM Innova, APQS, Gammill, Handi Quilter, Nolting, and more!
What is Added to my Machine?
- 7” or 10″ Android Tablet – Enjoy an easy-to-use, high-resolution touch display.
- Four Programmable Handle Bar Buttons – Perfect Stitch is the first machine that gave you programmable handle bar buttons.
- Adjustable, Ergonomic, Comfort Grip Handles – A day of quilting just got more comfortable.
- Rear Handle Bars – Outfitted with the same programmable buttons as the front handle bars. If you don’t already have rear handle bars, we’ll add them for you.
- New DC Brushless Motor – Our computer-controlled motor will adjust to you, ensuring that you never outrun your stitch regulator.
|Perfect Stitch Features|
|10″ Android or 7” Color Touch Screen Display|
|Adjustable, Ergonomic, Comfort Grip Handles|
|up to 22 Stitches per Inch|
|3,000 Precise Stitches per Minute|
|Bright LED Lights|
|Needle Position Sensor|
|Spring-Loaded 306 count quadrature Encoders|
|4 Programmable Shortcut Buttons|
|Total Run-time Timer|
|5 Quilter Profiles|
|180 watt NEMA23 motor|
Android Tablet Specs
|Display||Display Size||10.1 nch|
|Panel Type||TN screen HD|
|Touch Panel Type||Capacitive, Multi-touch 5 points|
|System||Processor||Rockchip 3168, Cortex A9, 1.2GHz|
|Operation System||Google Android 4.1.1|
|Storage drive(optional)||8GB Nand Flash|
|Camera||Front 0.3 MP, Back 2.0 MP|
|Speaker||1Wx 1 8ohm built-in speaker|
|I/O ports||SD Card||Micro SD Card(Up to 32GB) x1|
|USB port||1* Micro USB port|
|3G / GPS/ Bluetooth||External 3G|
|Mutimedia||Adobe Flash/HTML5||Support 11.X/HTML5|
|Video format||Max 1920*1080 pixels 1080P/ 3D/ Blue-ray Video output; DAT,MPG,VOB,TS /AVI, MKV, MP4, MOV, 3GP / RM, RMVB / WEBM / WMV, ASF / FLV|
|Audio format||MP3, WMA, MP2, OGG, AAC|
|Photo format||JPEG, GIF, BMP, PNG|
|Power & Battery||AC adapter||5V ~ 2A|
|Battery||Rechargeable Polymer Battery, 3.7 V, 4000mAh|
|WiFi browsering||5 hours|
|HDMI cable||HDMI Not Supported|
Precision Mode uses our powerful stitch regulation, allowing consistent stitch length at any free motion speed or style.
Manual Mode returns your quilting machine back to an unregulated mode. While the needle will move up and down at a constant rate, you can still adjust the speed the needle moves.
Idle Mode is a mix of the Precision Mode and Manual Mode– The needle will move up and down at a constant speed, letting you work by hand on the finer details, and then moves into regulated mode when you move the machine on the frame.
Baste Mode is a stitch regulated mode between 1-3 inches. Perfect for basting a quilt top.
High Performance Stitching
With performance settings ranging from 1-22 stitches per inch, and speeds of up to 3,000 stitches per minute, Perfect Stitch performs beyond expectation.
Perfect Stitch floods your quilt area with light right from the handle bars. Up to 40 Watts of adjustable white lighting! Also includes black lighting for your flourescent quilt projects.
Save your preferred machine settings, such handle bar buttons and SPI settings, to any of the 5 available machine profiles.
Needle up/down and tie-off controls
Needle up/down and tie-off controls – Control when to sew a single half stitch or full stitch, and perform a tie off stitch using a programmable number of stitches.
